Used Diesel Generator 100KVA

Get a Price/Quote

MOQ : 1 Piece

Used Diesel Generator 100KVA Specification

Fuel Tank Capacity
200 Litres

Engine Type
Other

Poles Number
4 Poles

Bore *Stroke
102 mm x 120 mm

Alternator
Brushless, Synchronous Alternator

Dimension (L*W*H)
3200 mm x 1100 mm x 1650 mm

Insulation
Class H

Fuel Consumption
18-20 Litres per hour @ full load

Protection Class
IP23

Standard
ISO 8528 Certified

Engine Model
Compatible with Cummins / Kirloskar / Mahindra, actual model may vary

Product Type
Used Diesel Generator

Output Type
AC Three Phase

Rated Power
100 KVA

Rated Voltage
415 V

Starting Type
Electric Start

Rated Frequency
50 Hz

Power Range
95-105 KVA

Color
Green

Cooling System
Water Cooled

Noise Level
75 dB(A) at 1 meter

Phase
Three Phase

Speed
1500 RPM

Weight
1200 kg (approx)

Lubrication Oil Capacity
18 Litres

Condition
Used, Fully Refurbished

Battery Included
Yes, heavy-duty battery supplied

Control Panel
AMF Panel Equipped

Soot Emission Level
Complies with CPCB norms

Make Year
2018-2020 (varies by availability)

Application
Industrial, Construction Sites, Commercial Backup

Mobility
Base mounted, forklift pockets

Voltage Regulation
+/- 1% (AVR controlled)

Hour Meter
Digital hour meter included

About Used Diesel Generator 100KVA

Used 100 KVA Diesel Generator is a cost-effective and dependable power solution for industrial, commercial, construction, and backup power applications. Thoroughly inspected and tested for performance, these generators deliver stable and efficient power while offering significant savings compared to purchasing new equipment. Designed to handle continuous and standby power requirements, a 100 KVA diesel generator is ideal for factories, warehouses, office buildings, construction sites, hospitals, hotels, and events.

Reliable Performance and Power

Delivering 100 KVA of rated power at 415V, this generator meets demanding requirements for industrial and commercial sectors. The engine, compatible with Cummins, Kirloskar, or Mahindra, ensures strong, consistent performance. Class H insulation and synchronous alternator technology offer efficient and safe electricity generation under varying load conditions.

Comprehensive Control and Monitoring

Supplied with an Automatic Mains Failure (AMF) control panel and a digital hour meter, the generator provides intuitive operation and user-friendly monitoring. These features help automate startup in case of power loss and simplify usage tracking for timely maintenance scheduling.

Durability and Compliance Assured

Refurbished to rigorous standards, this unit boasts a heavy-duty battery and robust protection (IP23). It complies with ISO 8528 and CPCB emission regulations, ensuring eco-friendliness and operational safety in all approved applications. Water-cooled and equipped with a noise control system, it maintains a comfortable 75 dB(A) at one meter.

FAQ's of Used Diesel Generator 100KVA:

Q: How does the AMF panel benefit the operation of this 100KVA used diesel generator?

A: The Automatic Mains Failure (AMF) panel automates the process of switching the generator on in the event of a mains power outage and off when power is restored, ensuring continuous power supply without manual intervention, which is especially useful for critical industrial and commercial applications.

Q: What is the typical usage process for this generator at a new location?

A: To use the generator at a new site, position the base-mounted unit using forklift pockets, ensure a stable foundation, connect the necessary electrical outputs, fill the fuel tank, check lubrication oil level, and use the electric start. The control panel and hour meter make operation and monitoring straightforward.

Q: When is maintenance required for this generator set?

A: Regular maintenance is advised according to the service guidelines, typically after every 250 running hours or as indicated by the digital hour meter. Maintenance tasks include checking lubrication oil (18L capacity), fuel system, cooling system, and electrical components to ensure optimal performance.

Q: Where can this generator be used most effectively?

A: The generator is designed for various demanding environments, including industrial plants, construction sites, and as commercial backup power. Its compliance with CPCB norms and water-cooled, robust build make it suitable for both outdoor and sheltered installations.

Q: What advantages does refurbished status offer compared to a new generator?

A: A fully refurbished generator offers lower acquisition costs while still delivering reliable performance. Components are restored and tested for quality, providing a cost-effective power solution with the backing of emissions and safety compliance.

Q: How does the generator ensure voltage stability during operation?

A: This generator comes equipped with AVR-controlled voltage regulation, ensuring output voltage variation remains within 1%, which protects sensitive equipment and reduces the risk of power fluctuations during operation.
